| Sr. |
Item |
Description |
| 1 |
Inner Seal (Chamber) |
SS 304L Thickness: 5mm |
| 2 |
Chamber Operating Pressure |
Negative pressure cycle |
| 3 |
Chamber Testing Pressure |
1.5 Kg/cm² |
| 4 |
Single Door |
SS 304L Thickness: 10mm |
| 5 |
Gasket |
Silicon Gasket (10/12 mm solid section) |
| 6 |
Steam Generator |
SS 316L Thickness: 3mm |
| 7 |
Outer cover |
Factory Finished (Poly-coated) MS |
| 8 |
Heating |
SS 316L Heaters on all sides of the Chamber for uniform heating throughout the load. |
| 9 |
Temp Sensor |
For accurate measuring and controlling of Temp. in the chamber |
| 10 |
Operating Temp |
Maximum: 45°C to 55°C (chamber)
(1) Medium Cycle: 35°C to 45°C
(2) Cool Cycle: 35°C to 40°C
(3) Hot Cycle: 48°C to 55°C |
| 11 |
RH% Sensor |
For measuring and controlling the humidity of the chamber |
| 12 |
Pressure Transmitter |
For measuring and controlling the pressure-vacuum that the load is subjected to during
removal and charging of Gas. |
| 13 |
All fittings on the Machine |
SS 304 |
| 14 |
All Valves for Automation |
Teflon construction Pneumatic valves, operated by Comp. Air supply through Solenoid
valves. |
| 15 |
Humidification |
Special Humidifier for the purpose of humidification of the load and heating of the gas. |
| 16 |
Vacuum |
Vacuum created by Ventury system. (Make: Festo) |
| 17 |
Automation Hardware |
PLC Make: Kinco HMI Make: Kinco |
| 18 |
Process Reports with thermal printer |
Reports are generated by the software for each and every cycle in three formats, viz. (i)
Single page Summary report and (ii) Detailed Report |
| 19 |
Testing |
Pressure / Vacuum testing as per specified standards. (1.5 times the working pressure) |
| 20 |
Operation |
All functions are electro-pneumatically operated. Door closing is manual |
| 21 |
Loading Trolley |
Fabricated with SS 304 |
| 22 |
Battery Backup |
UPS system will be provided for battery backup. If power failure it will usable for 20 minutes for continuous power supply. |
| 23 |
Air Filter |
0.2 micron air filter also provided with machine for fresh air. |
